Connects a multimode Gigabit Ethernet fiber optic network cable to a Cisco switch or server’s QSFP-DD port.
QSFP-DD Transceiver for Connecting to Your Cisco Network Switch or Server This QSFP-DD transceiver allows you to connect a multimode fiber optic cable to a 400 Gbps network router, server or switch. It transmits data up to 100 meters (328 feet) using an 850 nm wavelength. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.
Hot-Swappable for Installation Without Network Interruption This input/output device is fully hot-swappable, so you can install it without a potentially costly 400 Gbps network shutdown or device reboot. Just plug the QSFP-DD end of the transceiver into your Cisco network device. The other end has an MPO/APC connector to link with multimode fiber optic cable (sold separately). A push/pull tab connector is easily accessible in high-density data center applications and makes the plug-and-play transceiver easy to install and remove with one hand.
Functionally Equivalent to Cisco 400GBASE-SR8 Transceiver Module The MSA-compliant N286-400G-SR8-C functions just like the equivalent Cisco 400GBASE-SR8 transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the 400GBASE-SR8.
Supports Digital Diagnostic Monitoring (DDM) for Real-Time Status Monitoring DDM support lets you keep track of operating information in real time, such as transceiver temperature, input and output power and supply voltage.
SFP-transceivertype
Fiber optisk
Maksimal dataoverføringshastighet
400000 Mbit/s
Type grensesnitt
QSFP-DD
Multi-mode fiber (MMF) støttes
Ja
Fiberoptisk kontakt
MTP/MPO
SFP-sender standard
SR8
Maksimal overføring avstand
100 m
Bølgelengde
850 nm
Ethernet-fiberkabelteknologi
400GBASE
Digital diagnose Monitoring (DDM)
Ja
Produktfarge
Metallisk
Kroppsmateriale
Zink
Formfaktor
QSFP-DD
Plugg inn og spill
Ja
Hot-swap
Ja
Enkel installering
Ja
Merkekompatibilitet
Cisco
Samsvarssertifikat
CE, Federal Communications Commission (FCC), RoHS, UKCA
Sertifisering
EN 55032; IEC/EN 63000
Minimum driftstemperatur
0 °C
Maksimal opereringstemperatur
70 °C
Driftstemperatur (T-T)
0 - 70 °C
Oppbevaringstemperaturomåde (Celsius)
40 - 85 °C
Relativ luftfuktighet under drift (H-H)
5 - 85%
Vekt
50 g
Antall per pakke
1 stykker
Garantiperiode
3 år
Bærekraftsamsvar
Ja
Produktet har følgende varenummer i vårt system:
EAN:
0037332284129
SKU:
N286-400G-SR8-C
