Siemens 6GK5895-6ML10-0AA0 WLAN-antenne

ANT895-6ML antenna for GNSS L1 in frequency range from 1568 to 1618 MHz; integrated signal amplifier; incl. 0.3 m connection cable and N-Connect female connection; 3 dBi; IP67; -40...+85 °C mounting with magnet or screw fixing observe national approvals; scope of supply: 1x ANT895-6ML SCALANCE antennaANT895-6ML antennaFor receiving signals in a global navigation satellite system. These signals help determine the exact position and time of the connected device. Application examples: Time synchronization: Synchronization, e.g. of a church clock with UTC time (Coordinated Universal Time). The time is derived from the data of the GPS signal. Position detection/container tracking: A container can be tracked with the help of GPS position data, for example. Uniform time of all nodes in the communication network through synchronization with satellite time. Exact positioning or tracking of individual devices connected to GPS by evaluating the received signals. Integrated, low-noise signal amplifier for reliable evaluation of received data, even at low signal strength. Two-stage SAW filter with high attenuation allows the antenna to be placed close to other transmitting units.
